🔩 Insert Nut (Full Hex Body with Small Flange) | Neo Fasteners
Insert Nut (Full Hex Body with Small Flange) is a high-strength threaded insert designed to provide durable internal threads in wood, MDF, chipboard, plywood, and certain plastic materials.
The full hexagonal body offers maximum resistance against rotation inside the base material, ensuring a secure fit under heavy tightening torque. The small flange design allows a flush, neat surface finish, making it ideal for applications requiring strength without extra projection.
✅ Key Features
- Full Hex Body Design – Provides superior anti-rotation grip compared to semi-hex or round body inserts.
- Small Flange – Flush fitting with minimal surface projection, ensuring an aesthetic appearance.
- High Load-Bearing Capacity – Capable of handling repeated assembly/disassembly cycles.
- Strong Internal Threads – Accepts standard machine screws and bolts.
- Easy Installation – Can be press-fitted, hammered, or threaded into pre-drilled holes.
- Reusable & Durable – Protects against thread stripping in wood and softer materials.
🧱 Material & Finishes
-
Materials Available:
- Brass – Corrosion-resistant, best for furniture and decorative applications.
- Mild Steel (MS) – Cost-effective with zinc/nickel plating.
- Stainless Steel (SS 304 / SS 316) – High corrosion resistance and durability.
- Zinc Alloy – Economical with good rust protection.
-
Surface Finishes:
- Natural Brass Finish
- Zinc Plated (Clear / Yellow)
- Nickel Plated
- Black Oxide
📏 Available Sizes (Metric & Inch)
Metric Series (DIN / ISO Compatible)
| Thread Size | Body OD (D) | Length (L) | Flange OD (F) |
|---|---|---|---|
| M3 | 5.0 – 5.5 mm | 6 – 8 mm | 7.0 – 8.0 mm |
| M4 | 6.5 – 7.5 mm | 8 – 10 mm | 9.0 – 10.0 mm |
| M5 | 8.0 – 9.0 mm | 10 – 12 mm | 11.0 – 12.0 mm |
| M6 | 10 – 11 mm | 12 – 14 mm | 13.0 – 14.0 mm |
| M8 | 12 – 13 mm | 14 – 16 mm | 15.0 – 16.0 mm |
| M10 | 15 – 16 mm | 16 – 20 mm | 18.0 – 20.0 mm |
Inch Series (UNC/UNF)
| Thread Size | Body OD | Length | Flange OD |
|---|---|---|---|
| #8-32 | 0.20" | 0.30" – 0.45" | 0.28" – 0.32" |
| #10-24 | 0.25" | 0.35" – 0.50" | 0.35" – 0.40" |
| 1/4"-20 | 0.32" | 0.40" – 0.60" | 0.42" – 0.48" |
| 5/16"-18 | 0.40" | 0.50" – 0.70" | 0.50" – 0.55" |
| 3/8"-16 | 0.48" | 0.60" – 0.80" | 0.60" – 0.70" |
(Custom/OEM sizes also available.)
📐 Standards & Certifications
- Manufactured as per DIN 16903 (Threaded Inserts for Plastics/Wood)
- ISO 9001:2015 Certified Manufacturing
- RoHS Compliant – Free from hazardous substances (EU Directive 2011/65/EU & EU 2015/863)
🧰 Applications
- Furniture Assembly – Beds, wardrobes, chairs, cabinets
- Woodworking – MDF, chipboard, particleboard installations
- Automotive & Machinery – Secure fastening in plastic or wooden components
- Electronics Enclosures – Threaded inserts in housings & cases
- DIY & Modular Systems – Knock-down and flat-pack assembly
📦 Packaging & Supply
- Standard Packs: 100 / 500 pcs in sealed polybags
- Bulk Supply: 5,000 pcs in master cartons
- OEM Options: Branding, custom labeling & barcoding available
